FW2 1/4" BSPT Stainless Steel 16-Hole Flat Fan Air Nozzle
Description
The FW2 Stainless Steel Flat Fan WindJet Air Nozzle is an industrial compressed air nozzle manufactured from high-quality stainless steel, offering exceptional strength, corrosion resistance, and the capability to withstand high-temperature environments.
The nozzle is engineered to deliver a flat fan air pattern through 16 precision orifices, ensuring uniform air distribution, high impact force, and optimal coverage for continuous blowing applications across industrial production lines. It is ideal for cooling, drying, surface cleaning, liquid blow-off, and conveyor system applications, effectively reducing compressed air consumption, minimizing noise levels, and enhancing overall plant efficiency.
Featuring a standard 1/4″ BSPT male thread connection for easy installation, this nozzle supports a maximum operating temperature of 300°C and a maximum air pressure of 15 bar.
Technical Specifications
| Specification | FW2-ABS | FW2-AL | FW2-SS |
| Image |  |  |  |
| Air Outlet Holes | 16 Holes | 16 Holes | 16 Holes |
| Material | ABS Plastic | Aluminum Alloy | Stainless Steel |
| Air Pattern | Flat Fan Air Pattern | Flat Fan Air Pattern | Flat Fan Air Pattern |
| Thread Size | 1/4″ BSPT | 1/4″ BSPT | 1/4″ BSPT |
| Maximum Operating Temperature | 77°C | 250°C | 300°C |
| Maximum Operating Pressure | 7 Bar | 10 Bar | 15 Bar |
| Recommended Applications |
|
|
|
| Key Features | Manufactured from high-quality ABS plastic. Lightweight, corrosion-resistant, and cost-effective | Manufactured from high-quality aluminum alloy, offering excellent strength, lightweight construction, and high-temperature resistance | Energy-saving and noise reduction with high strength, durability, and a long service life made of genuine, rust-free stainless steel material. |
Key Features
Manufactured from high-quality stainless steel for exceptional strength, durability, and corrosion resistance.
Delivers a flat fan air pattern for uniform air distribution.
Features 16 air orifices to enhance blowing efficiency and consistency.
Withstands a maximum operating temperature of 300°C.
Supports a maximum air pressure of 15 bar.
Reduces compressed air consumption and minimizes noise levels during operation.
Easy to install with a standard 1/4″ BSPT male thread.
Provides a long service life, ideal for heavy-duty industrial applications.
Application
The FW2 stainless steel air nozzle is ideal for industrial applications requiring high durability, such as:
Cooling systems
Drying processes
Parts cleaning and blow-off
Liquid and water blow-off from workpieces
Conveyor systems
Food and beverage industry
Packaging industry
Plastics industry
Automotive industry
Automated machinery
Performance Data
Ordering Information
FW2-AL Aluminum alloy material
FW2-ABS Plastic material
FW2-SS Stainless steel material
